135 Series Standard Carbide Circuit Board Drills
Quality Tech Series 135 Drills are specifically designed for production of high quality holes in all double-sided, multilayer or flex circuit boards. Available in diameters .0135 - .1250

136 Series Extended Flute Drills
Series 136 Drills are designed for drilling depths beyond the normal aspect ration in multilayer or double-sided boards. Drills are made with sub-micron carbide that has a very high T.R.S. which is essential for this drill design to control drill breakage and registration. Available in diameters .0135 - .1250

137 Series Micro Drills
Series 137 Micro Drills have all the essentials for micro hole drilling applications. The step-down body design for added strength is supported by a 1/8" shank. Use of sub-micron carbide with its very high T.S.R. gives added strength. T.I.R. is held to .0001 to help minimize breakage. Available in diameters .004 - .0130

138 Series Undercut Multilayer Circuit Board Drills
Series 138 Undercut Drills are designed especially for drilling multilayer boards. With undercut geometry on the O.D., together with proper flute form for maximum chip flow, the risk of epoxy smear or thermal build-up is reduced. Hole accuracy and location are easily obtainable. Available in diameters .0135 - .1250

139 Series Slotting Drills
Series 139 Slotting Drills are designed to resist deflection when drilling out slots. Available in diameters .0177 - .1250

140 Series Reverse Shank Drills
Series 140 Reverse Shank Drills are manufactured in one solid carbide piece construction and are designed to keep bird nesting at a minimum. Thin webs along with fluting extended into the shank allows for extra repoints. The entire drill diameter is margin relieved. Available in diameters .1260 - .3750

ROUTER BITS

201 (Upcut Slow Spiral) & 205 Series Routers (Upcut Fast Spiral)
Series 201 & 205 Series Routers are available with fishtail, drill point or non-cutting end geometry. With upcut design chips are drawn up to assist vacuum system. Clean, burr-free cutting with maximum tool life is realized when tools are used on well-maintained equipment that incorporates pressure footboard holding system.

206 (Downcut Slow Spiral) & 202 Series Routers (Downcut Fast Spiral)
Series 206 & 202 Series Routers are designed to hold the board down while routing. This cutting tooth configuration will produce a clean, smooth finish. These routers are available with fishtail, drill point or non-cutting end geometry.

203 (Upcut Chipbreakers) & 204 Series Routers (Downcut Chipbreakers)
Series 203 Routers create an upward chip flow to accommodate a vacuum system. Consistent clean surfaces and extended tool life is achievable when used in conjunction with the latest routing equipment. The chipbreaking action of this style router insures a fine, burr-free finish. Ideal for use on polyimide quartz boards. Series 204 is designed to hold the board down during routing. This style will also help in preventing possible delamination. Ideal for use on polyimide quartz boards.

SPECIALTY TOOLS

207 Series 2 Flute End Mills
Series 207 End Mills are produced with high positive rake and greater clearance angles to maintain a sharper and freer cutting edge on non-ferrous materials. Ideally suited for routing teflon, flexible boards, aluminum and plastic type materials.

208 Series Beveling Tools
Series 208 Beveling Tools have the geometry to bevel cut with the tool's O.D. or end cut. They are suited for fiberglass epoxy and copper/nickel/gold compositions.

209 Series 2 Soft Tooling Plug Drills- - - 2" OAL
Series 209 Drills are specially designed for accurate pinhole applications in soft tooling plugs.

503 Series 3 Straight Flute Routers
Series 503 Routers are specially designed for burr-free routing on C.I.C. and other hard circuit board materials.

107 Series Single Flute Routers
Series 107 Routers are specially designed for routing Teflon, Flex Boards and other soft materials.

501 Series 2 Flute Left Hand Spiral End Mills
Series 501 End Mills have down cut action and are designed to hold the work material down.

SP-45, SP-60 and SP-90 Series Spade Drills
These "V" Grove Cutters are designed to score top surfaces of board.

701 Series Countersinks
Standard head diameters are 1/8", 1/4" and 5/16" in 60, 82, 90 and 100 Degree included angels.
